Simarine VIA | SPDU66

12V Monitoring and Switching System
Measurements:
- 4x resistance measurement for temperatures or tank sensors
- 2x battery voltage or ultrasonic tank sensor inputs
- 100A shunt for main battery
- 50A shunt for DC/DC charger from starter to main battery
- 50A shunt for 230V/AC charger
- 50A shunt for solar

Switching:
2x fixed output
6x digital input for switching the 6 relays
12x fused output for consumers (max. 50A total)
- 6x relays, controllable from the VIA panel
- 6x outputs switchable via the main relay or additional external switches

Internal Reference: SPDU-66
Barcode: 3830067941582
Gross price incl. VAT: € 365,42
